Nano V3.0 Development Board ATmega328P

The Nano V3.0 Development Board ATmega328P is a compact and powerful microcontroller board designed for embedded systems, robotics, and IoT development. It is based on the ATmega328P 8-bit AVR architecture and provides the same core functionality as larger Arduino boards in a much smaller form factor.

This board is ideal for students, engineers, and developers who need a space-efficient solution for prototyping smart electronic systems. It supports real-time processing, multiple I/O interfaces, and seamless integration with sensors and modules used in automation projects.

The Nano V3.0 Development Board ATmega328P is widely used in robotics, smart devices, data logging systems, and educational electronics projects due to its reliability and ease of use.

Key Features

Compact Arduino-Compatible Design

The Nano V3.0 Development Board ATmega328P offers full Arduino compatibility in a small breadboard-friendly layout.

ATmega328P Microcontroller

Powered by a reliable 8-bit AVR processor running at 16 MHz for stable and efficient performance.

USB Interface Support

Includes USB Mini-B interface for easy programming, debugging, and power supply.

Multiple I/O Pins

Provides digital and analog pins for connecting sensors, actuators, and communication modules.

PWM Output Support

Six PWM-enabled pins allow control of motors, LEDs, and servo systems.

Onboard Voltage Regulation

Built-in regulator ensures stable 5V operation from external power sources.

How It Works

The Nano V3.0 Development Board ATmega328P executes instructions written in Arduino IDE or other programming environments. It processes input signals from sensors, executes logic operations, and controls output devices such as motors, relays, and displays.

The onboard ATmega328P microcontroller handles all computation tasks while external components expand functionality for real-world applications.

External reference:
https://en.wikipedia.org/wiki/ATmega328

Pin Configuration Overview

Power Pins
VIN: External power input (7V–12V)
5V: Regulated output supply
3.3V: Low voltage output
GND: Ground connection

Digital Pins (D0–D13)
Used for input/output operations including communication, switching, and control signals.

Analog Pins (A0–A7)
Used for reading analog sensor values with 10-bit resolution.

PWM Pins
Used for motor speed control, LED dimming, and servo control applications.

Compatibility

Arduino IDE

The Nano V3.0 Development Board ATmega328P is fully compatible with Arduino IDE for easy programming and deployment.

https://www.arduino.cc/reference/en/

PlatformIO and Advanced Development

Supports professional embedded development environments for optimized firmware programming.

Robotics and IoT Systems

Ideal for integration with sensors, wireless modules, and automation systems including ESP8266 and ESP32 setups.

ESP8266 reference:
https://en.wikipedia.org/wiki/ESP8266

Rudr Mart All Products

Applications

Robotics and automation systems
Smart home devices
Sensor-based monitoring systems
IoT data logging projects
Educational STEM kits
Motor and servo control systems
Custom electronic prototypes
Embedded control systems

Technical Specifications
